ITUS Max

US-Patented Intelligence for Every Brand and Powertrain
US-Patented Intelligence for Every Brand and Powertrain

US‑Patented EV Scanner for Every Brand and Powertrain

High-frequency telemetry and battery data capture. Edge encryption. No rewiring, just plug and drive.
ukca
rohs
CE
1p67
The Hardware Layer That Closes the EV Intelligence Gap


The Hardware Layer That Closes the EV Intelligence Gap

EV fleets face EV-specific challenges that traditional telematics cannot solve. ITUS Max is Datakrew’s automotive-grade IoT vehicle scanner, a secure, plug-and-play bridge between any vehicle and Datakrew’s OXRED MyFleet platform.
It plugs into the OBD-II port, reads CAN bus data, and captures high-resolution battery, driving, charging, and telemetry data every 10 seconds. There is no rewiring and no delays. Just plug and drive.
ITUS Max works with any EV, hybrid, or ICE vehicle. It is OEM-agnostic, globally compatible across 140+ countries, and built to survive the harshest fleet environments.
notion image

Install ITUS Max in 3 Simple Steps

01.

Locate the OBD-II Port

Find your vehicle's OBD-II port. It is typically under the driver's seat, steering wheel, or dashboard. No special tools are required.

02.

Plug in the Device

Insert the ITUS Max connector firmly into the OBD-II port. The included
0.5-meter cable ensures a secure, plug-and-play fit.

03.

Turn Ignition ON

Power on the vehicle. ITUS Max auto-configures for your vehicle model and begins transmitting data to OXRED MyFleet within seconds.
notion image

Why ITUS Max is a Game Changer

notion image

Truly Agnostic

Pre-configured for 50+ EV models and counting. Over-the-air updates delivered via FUOTA add new vehicle support without downtime. No rewiring. No delays. Just plug and drive.

notion image

Ultra-Secure

On-board crypto chip ensures secure boot and encrypted key storage. All data flows through encrypted HTTPS and MQTTS. Built to support post-quantum cryptography in compliance with NIST and ISO standards.
notion image

Sensing + Local Resilience

Built-in accelerometer and gyroscope detect harsh driving, collisions, and erratic turns in real time. Continuous battery data capture monitors health and performance metrics, stored securely on solid-state FeRAM even during sudden power loss.
notion image

Sensing + Local Resilience

Built-in accelerometer and gyroscope detect harsh driving, collisions, and erratic turns in real time. Continuous battery data capture monitors health and performance metrics, stored securely on solid-state FeRAM even during sudden power loss.
notion image

Global Compatibility

4G LTE with 2G fallback. Auto-roaming across 140+ countries. Tamper-proof SIM locks out misuse. No more SIM swaps or network dead zones.
notion image

Global Compatibility

4G LTE with 2G fallback. Auto-roaming across 140+ countries. Tamper-proof SIM locks out misuse. No more SIM swaps or network dead zones.

notion image

Superior Compression

Compresses data by up to 80% for faster transmission and lower bandwidth bills. Zero compromise on visibility or accuracy.
notion image

Ingress Protected

From heat to humidity, dust to downtime. ITUS Max is built for harsh fleet environments with IP67 enclosure and EMC-safe internals. Certified and field-proven across millions of kilometres.
notion image
Enterprise-Grade Hardware, Built for Global Deployment
notion image
High-frequency telemetry and battery data capture for extreme environments.
notion image
ARM Cortex-M33 processor. 64KB FeRAM. 128MB Flash.
notion image
Post-quantum encryption compliant with NIST and ISO
notion image
4G LTE with 2G fallback. Auto-roaming across 140+ countries
notion image
IP67 enclosure. Solid-state design. No data corruption

ITUS Max Specifications

Detailed Specifications
Detailed Specifications

Connectivity

4G LTE. 2G fallback. 140+ countries.

Global Coverage

Tamper-proof SIM. Global roaming.

Vehicle Support

50+ EV models. CAN FD and 2.0B.

OBD Interface

Plug-and-play 16-pin OBD-II port.

Security

NIST and ISO compliant encryption.

Data Storage

64KB FeRAM. 128MB Flash. No SD.

Sensors

Accelerometer. Gyroscope. GNSS.

Protection

IP67 enclosure. EMC-safe internals.

Certification

CE, UKCA, and RoHS certified.

Data Compression

Up to 80% bandwidth compression.

Perfect For

notion image
Commercial Fleets
Logistics, delivery, and transportation fleets need real-time monitoring and optimisation. ITUS Max delivers high-resolution vehicle data to improve fleet visibility, reduce downtime, and support safer operations across EV, hybrid, and ICE fleets.
notion image
Insurers
Usage-based insurance and claims workflows need trusted vehicle data. ITUS Max delivers high-fidelity, tamper-resistant data on driving behaviour, vehicle condition, and safety metrics to surface anomalies early and support faster, more efficient decisions.
notion image

Ready to Bring Intelligence to Your Fleet?

Book a demo with our team to see how ITUS Max and OXRED MyFleet transform your fleet operations.
